Brompton Electric T Line 1-speed - Mid rise bar

1. Frame

Main frame:

• Grade 9 titanium tubes
• welded main frame
• cast titanium bottom bracket manifold

Rear Triangle:

• Advance Superlight rear frame
• replaceable derailleur hanger
• advance suspension block
• large 54mm roller wheels

Fork:

• One piece carbon fork and steerer
• integrated magnetic pedal holder

2. Size and Weight

Folded size: 599mm wide x 645mm tall by 320mm deep
Weight: 14kg

3. Colour

• Main frame: Blasted Titanium
• Handlebar stem: Blasted Titanium
• Forks: Black carbon
• Rear triangle: Blasted Titanium
• Decal: Silver
• Detailing: Black

4. Handlebars and grips

• Superlight Carbon mid rise handlebars (previously known as the M type) - similar to the the classic Brompton handlebar shape - 31.8mm diameter
• Superlight lock-on foam grips (130mm and easily changeable with your favourite grips if wanted)
• Handlebar width - 58cm
• Handlebar controller for electric system

5. Gears / drivetrain

• Electric powered single speed
• Brompton Greenway removable battery

• Lightweight crankset with torque sensing bottom bracket
• Brompton advance chain with connecting link
• Superlight pedals (the right one is removable) which were introduced with the T Line
• Single rear rear sprocket for simplicity

6. Front luggage system

• Electric front carrier block
• T Line essentials bag included - the toughest bag Brompton have ever made?

7. Mudguards / Rack / Hinge clamps

• This bike comes with no mudguards - to save weight
• No rack / roller frame is included - though it and mudguards could be retro-fitted
• Self aligning aluminium hinge clamps to help you un-fold quicker

8. Roller wheels

• New advance roller wheels help keep the bike stable when folded

9. Tyres / Wheels

Schwalbe ONE with Addix race compound and v-guard puncture protection
16 inch (ETRTO size 349) wheels with double wall rim

• 28 spokes  on the rear - Lightweight rim, double butted spokes, aluminium hub body and 4 speed freehub body
• 20 spokes on the front - Lightweight rim, double butted spokes and aluminium hub with sealed bearings and Allen key axle

The wheels have black hubs, black spokes and black rims (the braking surface is still silver)
Inner tubes -  Tubolito 34g tube with Presta/racing type valve

10. Saddle and pump

• Brompton superlight carbon saddle, this superlight carbon saddle features carbon rails, a carbon reinforced base and lightweight padding, it features a low profile and wave shape and has the under saddle mounting for the Be Seen Lights
• Fitted with the superlight pentaclip which is a machined aluminium seat clamp and rear frame clip in anodized matt black finish
• Pump not included but can be purchased seperately

11. Seat height

Standard height steel armoured carbon seatpost for riders with an inside leg measurement of up to 33 inches
If you are taller - up to 35 inch inside leg - then an extended length carbon seatpost can be fitted at no extra cost
For very tall riders a telescopic seatpost is available at extra cost - sorry a carbon version is not available

Saddle height insert is included - try riding the bike for a while to get used to your ideal / optimum seat height before fitting

12. Suspension

• Along with the new T Line came a new advance suspension block - also used on the T Line Electric

13. Lighting / reflectors

• Brompton Electric lights (front and rear) are included
